Barrel cleaner

ONEPLEX Semi-automatic barrel cleaning system

The Semi-Automatic Barrel Washer Oneplex 225l is a portable unit designed for the efficient and safe cleaning of barrels of 225 liters. Its multidirectional rotation washing system allows, in just 90 seconds, a high-pressure jet of cold or hot water to reach all interior surfaces of the barrel, ensuring optimal cleaning.

For proper operation, it needs to be connected to a high-pressure washer operating between 60 and 100 bar. The unit supports water temperatures up to 90ºC, offering flexibility based on specific cleaning needs.

Technical Specifications

  • Antrieb

    Elektrisch Elektrisch
  • Reinigungskopf

    RK37 RK37
  • Strahlabdeckung

    360° 360°
  • Geschwindigkeit

    17rpm 17rpm
  • Zyklus komplett

    3 min 3 min
  • Arbeitsdruck max.

    120 bar 120 bar
  • Arbeitsdruck min.

    80 bar 80 bar
  • Durchfluss max.

    20 l/m 20 l/m
  • Durchfluss min.

    13 l/m 13 l/m
  • Temperatur max.

    90°C 90°C
  • Material

    1.4301 1.4301
  • Anschluss

    M22x1.5 M22x1.5
  • Control panel

    with timer with timer
  • Fassgrösse

    225l 225l
  • Article number

    PR.000.169 PR.000.169
